Pistons shown with bearings for illustration only.
Bearings sold separately.
Piston types are universal for all current Tilton hydraulic release bearings. Please select your bearing model number, and then desired length
Tilton Engineering Hydraulic Release Bearing Pistons
$85.00
Description
Pistons shown with bearings for illustration only.
Bearings sold separately.
Piston types are universal for all current Tilton hydraulic release bearings. Please select your bearing model number, and then desired length.
If you are looking to replace a piston for a legacy Tilton product, please contact your local distributor, or Tilton directly, to check on availability.
| BEARING TYPE | PART NUMBER |
|---|---|
| 38mm | Varies. Reference above pull-down menu options and SKU. |
| 44mm | Varies. Reference above pull-down menu options and SKU. |
| 52mm | 62-612 |
| Flat-face | 62-6100 |
Specs:
| Release Bearing Model | 60-X0XX (52-mm radius-face bearing), 60-X1XX (Flat-face bearing), 60-X2XX (44-mm radius-face bearing) / 60-X3XX (38-mm radius-face bearing) |
|---|---|
| Piston Length | 1.215″ (30.9mm), 1.315″ (33.4mm), 1.415″ (35.9mm), 1.515″ (38.5mm), 1.615″ (41.0mm), 1.715″ (43.6mm), 1.815″ (46.1mm), 1.915″ (48.6mm), 2.015″ (51.2mm), 2.115″ (53.79mm), 1.530″ (38.9mm), 1.240″ (31.5mm) |
